ECS | SOCKET AMD AM3+ || A960-M2

Nama Product ECS | SOCKET AMD AM3+ || A960-M2
Harga Rp 570.000
CPU º Supports AMD AM3+ FX™/Phenom™ II/Athlon™ II/Sempron™ 100 Series
º Support 125W AM3+ FX™/ Phenom™ II X6 processors
º High-performance HyperTransport 3.0 CPU Interface
º Note: This board supports CPU up to 125W TDP ; you can refer to AMD website to check your CPU.
CHIPSET º AMD® 760G & AMD® SB710
º North Bridge: AMD® 760G
º South Bridge: AMD® SB710
GRAPHICS º On chip (AMD® 760G-based with ATI™ Radeon HD3000 graphics)
º Integrated DirectX 10 graphics processor
º Share Memory: Maximum up to 512MB
MEMORY º Dual-channel DDR3 memory architecture
º 2 x 240-pin DDR3 DIMM socket support up to 16 GB*
º Supports Dual-DDR3 up to 1866 with AM3+ CPU
º Supports Dual-DDR3 1333 / 1066 with AM3 CPU
º *(Due to AMD CPU spec limitation, please refer to Memory QVL for more information)
º *(Due to the DRAM maximum size is 4GB at present, the memory maximum size we have tested is 8GB)
Due to the operating system limitation, the actual memory size may be less than 4GB for the reservation for system usage under Windows® 32-bit OS.
For Windows® 64-bit OS with 64-bit CPU, there is no such limitation
EXPANSION SLOT º 1 x PCI Express x16 Gen2.0 slot
º 1 x PCI Express x1 slot
º 2 x PCI slots
STORAGE º Support by AMD® SB710
    • RAID0, RAID1, RAID10 configuration
    • 6 x Serial ATA 3.0Gb/s devices
AUDIO º VIA® VT1705 6-channel audio CODEC
º Compliant with HD audio specification
LAN º Realtek 8111E Gigabit LAN Fast Ethernet Controller
º Realtek 8105E 10/100 Lan(Optional)
REAR PANEL I/O º 1 x PS/2 keyboard & PS/2 mouse connectors
º 1 x HDMI Port(Optional)
º 1 x DVI connector(optional)
º 1 x D-sub(VGA)
º 1 x Serial port (COM1)
º 1 x RJ45 LAN connector
º 1 x Audio port (Line-in, Line-out, Mic-in)
º 4 x USB 2.0 Ports
INTERNAL I/O CONNECTORS & HEADERS º 1 x 24-pin ATX Power Supply connector
º 1 x 8-pin ATX 12V Power Connector
º 1 x 4pin CPU_FAN connectors
º 1 x 3-pin SYS_FAN connector
º 1 x IDE connector
º 1 x Speaker header
º 1 x Front panel switch/LED header
º 1 x Front panel audio header
º 1 x SPDIF out header
º 1 x Clear CMOS header
º 1x CD in header
º 1 x Parallel Header
º 6 x Serial ATA 3Gb/s connectors
º 1 x Chassis intrusion header
º 2 x USB 2.0 headers support additional 4 USB 2.0 Ports
º Supports Plug and Play, STR (S3) / STD (S4) , Hardware monitor, Multi Boot
º Audio, LAN, can be disabled in BIOS
º F11 hot key for boot up devices option
º Support over-clocking
º Support eJIFFY
º Support eBLU
º Support eDLU
º Support eOC
º Support ECS M.I.B III Utility
º CPU voltage adjustable
º Memory voltage adjustable
    • NB Chipset Voltage Adjustable
    • SB Chipset Voltage Adjustable
    • HT Voltage Adjustable
    • External Clock Adjustable
    • Multiple Frequency Adjustable
FORM FACTOR º Micro-ATX Size, 244mm*210mm
Available Stock Ready
